Jinkebotong Environmental Protection Technology (Jiangsu) Co., Ltd
$30000-400000 /Set/Sets
Packaging: Wooden Box Package
Productivity: 1000 PCS/Year
Transportation: Ocean
Place of Origin: china
Supply Ability: 100 sets
Certificate: ISO9001
HS Code: 8479820090
Port: shanghai
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF
Brand: jinkebotong
Origin: china
Certification: ISO9001
Place Of Origin: China
Status: New
Video Factory Inspection: Provided
Mechanical Test Report: Not Available
Marketing Type: Ordinary Product
Core Component Warranty Period: 1 Year
Core Components: Plc, Motor, Pressure Vessel, Gear
Warranty Period: 1 Year
Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Online Support, Spare Parts
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None
Applicable Industry: Manufacturing Plant
Showroom Location (in Which Countries Are There Sample Rooms Overseas): None
Specification: 1800*1950*1800MM
Barrel Volume (L): 300
Max.Loading(Kg): 150
Hybrid Speed (R/Min): 0-15
Weight (Kg): 1050
Overall Size(mm): 1900*2000*1900
Working Volume (L): 240
Power: 0.73kw
| Selling Units: | Set/Sets |
|---|---|
| Package Type: | Wooden Box Package |
The file is encrypted. Please fill in the following information to continue accessing it
Technical parameters:
| Type | Material barrel volume (L) | Max loading volume (L) | Max loading weight (kg) | Spindle rotation speed (r/min) | Motor power (kw) | Overall dimensions (mm) | Weight (kg) |
| SWH-5 | 5 | 4 | 5 | 24 | 0.37 | 600*1000*1000 | 150 |
| SWH-50 | 50 | 40 | 40 | 15 | 0.75 | 970*950*1200 | 440 |
| SWH-100 | 100 | 80 | 80 | 15 | 2.2 | 1200*1800*1500 | 500 |
| SWH-200 | 200 | 150 | 150 | 12 | 3 | 1300*1600*1500 | 750 |
| SWH-400 | 400 | 300 | 200 | 10 | 4 | 1500*2200*1500 | 1200 |
| SWH-600 | 600 | 450 | 300 | 10 | 5.5 | 1850*2500*1650 | 1500 |
| SWH-800 | 800 | 600 | 400 | 10 | 7.5 | 1900*2400*2100 | 1650 |
| SWH-1000 | 1000 | 750 | 500 | 10 | 11 | 1950*2500*2400 | 1800 |
| SWH-1500 | 1500 | 1200 | 750 | 10 | 18.5 | 2600*2500*2350 | 2500 |
