Jinkebotong Environmental Protection Technology (Jiangsu) Co., Ltd
$30000-400000 /Set/Sets
Packaging: Wooden Box Package
Productivity: 1000 PCS/Year
Transportation: Ocean
Place of Origin: china
Supply Ability: 100 sets
Certificate: ISO9001
HS Code: 8479820090
Port: shanghai
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF
Brand: jinkebotong
Place Of Origin: China
Status: New
Video Factory Inspection: Provided
Mechanical Test Report: Not Available
Marketing Type: Ordinary Product
Core Component Warranty Period: 1 Year
Core Components: Plc, Motor, Pressure Vessel, Gear
Warranty Period: 1 Year
Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Online Support, Spare Parts
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None
Applicable Industry: Manufacturing Plant
Showroom Location (in Which Countries Are There Sample Rooms Overseas): None
Barrel Volume (L): 300
Max.Loading(Kg): 150
Hybrid Speed (R/Min): 0-15
Weight (Kg): 1050
Overall Size(mm): 1900*2000*1900
Working Volume (L): 240, 240
Specification: 1800*1950*1800MM
Power: 0.73kw
| Selling Units: | Set/Sets |
|---|---|
| Package Type: | Wooden Box Package |
The file is encrypted. Please fill in the following information to continue accessing it
| Model | SZH-300 | SZH-500 | SZH-1000 | SZH-1500 | SZH-2500 | SZH-4000 | SZH-6000 | SZH-8000 |
| Production Capacity (kg/batch) | 150 | 250 | 500 | 750 | 1250 | 2000 | 3000 | 4000 |
| Overall Volume (m3) | 0.3 | 0.5 | 1 | 1.5 | 2.5 | 4 | 6 | 8 |
| Mixing Time (min) | 4-8 | 4-8 | 6-12 | 6-12 | 6-12 | 6-15 | 6-15 | 6-15 |
| Motor Power (Kw) | 1.1 | 2.2 | 3 | 4 | 5.5 | 7.5 | 11 | 15 |
| Cylinder Speed (rolling/min) | 15 | 15 | 12 | 12 | 12 | 10 | 10 | 10 |
| Overall Dimensions (L × W × H) | 1680 × 650 × 1600 | 2080 × 750 × 1900 | 2150 × 850 × 2100 | 2300 × 1600 × 3100 | 2500 × 100 × 2450 | 2980 × 1580 × 2800 | 3500 × 1800 × 3000 | 3980 × 2000 × 3200 |
| Mixer Weight (kg) | 310 | 550 | 800 | 950 | 1650 | 1880 | 2350 | 2680 |
