 Products> Mixer> Two-dimensional Mixer> Stainless steel V-shaped mixer

Stainless steel V-shaped mixer

$30000-500000 /Set/Sets

Contact Now

Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF
Min. Order: 1 Set/Sets
Transportation: Ocean
Port: shanghai

Supply Ability & Additional Information

Additional Information

Productivity: 500 Sets/Year

Transportation: Ocean

Place of Origin: china

Supply Ability: 500 Sets/Year

Certificate: ISO9001

HS Code: 847982

Port: shanghai

Payment Type: L/C,T/T

Incoterm: FOB,CFR,CIF

Product Attributes

Model No.: VH

Brand: jinkebotong

Place Of Origin: China

Status: New

Video Factory Inspection: Provided

Mechanical Test Report: Not Available

Marketing Type: Ordinary Product

Core Component Warranty Period: 1 Year

Core Components: Plc, Motor, Pressure Vessel, Gear

Warranty Period: 1 Year

Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Spare Parts, Online Support

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Applicable Industry: Manufacturing Plant

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Specification: 2000X3000X2000

Production Capacity: 200, 5-1500kg

Model NO.: EYH

Voltage: 220V

Weight(Kg): 620

Motor: 3kw

Packaging & Delivery

Selling Units:	Set/Sets

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

Product Description
V Shape Mixer applied to good liquidity dry powder and granular material mixing in pharmacy industry, chemical industry, food industry. This machine mixing cylinder structure special, efficiency is high, no blind angle,material adopt stainless steel, wall polishing treatment, nice,appearance,equally mixing.

The material in the V-type mixing container flows smoothly without damaging the original material.It can be designed as single arm or double arm according to customer requirements.

Application
The mixer is used for mixing the dry material grains in the medical, chemical, food, metallurgical and other industries.
The mixing barrel structure is unique. The mixing efficiency is high. There is no corner that can not be reached. The barrel uses the stainless steel and its internal and external walls are polished. The outside appearance is beautiful. The mixing is uniform, with wide application. The mixer meets GMP standard.

Technical parameters:

Spec\item	Total volume L	Working cpacity L	Working capacity kg	Rotating speed rpm	Power kw	Weight kg
VH-50	50	25	15	25	0.55	500
VH-150	150	75	45	20	0.75	650
VH-300	300	150	90	20	1.1	820
VH-500	500	250	150	18	1.5	1250
VH-1000	1000	500	300	15	3	1800
VH-1500	1500	750	450	12	4	2100
VH-2000	2000	1000	600	12	5.5	2450
VH-3000	3000	1500	900	9	5.5	2980
VH-4000	4000	2000	1200	9	7.5	3300
VH-5000	5000	2500	1500	8	7.5	3880
VH-6000	6000	3000	1800	8	11	4550
VH-8000	8000	4000	2400	6	15	5200
VH-10000	10000	5000	3000	6	18.5	6000
