Jinkebotong Environmental Protection Technology (Jiangsu) Co., Ltd
$30000-400000 /Set/Sets
Packaging: Wooden Box Package
Productivity: 1000 PCS/Year
Transportation: Ocean
Place of Origin: china
Supply Ability: 100 sets
Certificate: ISO9001
HS Code: 8479820090
Port: shanghai
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF
Model No.: SBH
Brand: jinkebotong
Place Of Origin: China
Status: New
Video Factory Inspection: Provided
Mechanical Test Report: Not Available
Marketing Type: Ordinary Product
Core Component Warranty Period: 1 Year
Core Components: Plc, Motor, Pressure Vessel, Gear
Warranty Period: 1 Year
Out-of-warranty Service: Video Technical Support, Field Maintenance And Repair Service, Online Support, Spare Parts
Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None
Applicable Industry: Manufacturing Plant
Showroom Location (in Which Countries Are There Sample Rooms Overseas): None
Barrel Volume (L): 300
Max.Loading(Kg): 150
Hybrid Speed (R/Min): 0-15
Weight (Kg): 1050
Overall Size(mm): 1900*2000*1900
Working Volume (L): 240, 240
Specification: 1800*1950*1800MM
Power: 0.73kw
| Selling Units: | Set/Sets |
|---|---|
| Package Type: | Wooden Box Package |
The file is encrypted. Please fill in the following information to continue accessing it
Technical parameters:
| Type | Material barrel volume (L) | Max loading volume (L) | Max loading weight (kg) | Spindle rotation speed (r/min) | Motor power (kw) | Overall dimensions (mm) | Weight (kg) |
| SWH-5 | 5 | 4 | 5 | 24 | 0.37 | 600*1000*1000 | 150 |
| SWH-50 | 50 | 40 | 40 | 15 | 0.75 | 970*950*1200 | 440 |
| SWH-100 | 100 | 80 | 80 | 15 | 2.2 | 1200*1800*1500 | 500 |
| SWH-200 | 200 | 150 | 150 | 12 | 3 | 1300*1600*1500 | 750 |
| SWH-400 | 400 | 300 | 200 | 10 | 4 | 1500*2200*1500 | 1200 |
| SWH-600 | 600 | 450 | 300 | 10 | 5.5 | 1850*2500*1650 | 1500 |
| SWH-800 | 800 | 600 | 400 | 10 | 7.5 | 1900*2400*2100 | 1650 |
| SWH-1000 | 1000 | 750 | 500 | 10 | 11 | 1950*2500*2400 | 1800 |
| SWH-1500 | 1500 | 1200 | 750 | 10 | 18.5 | 2600*2500*2350 | 2500 |
The mixing cylinder features a 360-degree multi-directional movement function, enabling numerous intersections of materials within the cylinder and resulting in a high mixing effect. During the mixing process, the flow and diffusion of various materials are accelerated. At the same time, it avoids the segregation and accumulation of material specific gravity caused by centrifugal force in general mixers. There is no dead angle in mixing, which can effectively ensure the optimal quality of the mixed material. The maximum loading coefficient can reach 0.8. With short mixing time and high efficiency, the machine is composed of components such as a base, a transmission system, an electrical control system, a multi-directional motion mechanism, and a mixing cylinder. The mixing cylinder directly in contact with the material is made of high-quality stainless steel. The inner and outer walls of the cylinder are polished, presenting a neat and beautiful appearance.
